translate: turn an ONNX model back into Python code#

translate() converts an existing ModelProto (or GraphProto) into Python code that rebuilds an equivalent model. Two flavours are available:

api="onnx-compact" — a single nested onnx_light.onnx.helper expression (oh.make_model(oh.make_graph([...], ...))).
api="builder" — an incremental script driving the GraphBuilder (g.make_input(...), g.make_node(...), g.to_onnx(...)).

translate_header() returns the matching import header, so translate_header(api) + translate(model, api) is a fully runnable Python snippet. The example below builds a small model, prints both flavours and then executes the generated code to rebuild the model.

from __future__ import annotations

import numpy as np

import onnx_light.onnx as onnx
import onnx_light.onnx.defs as defs
import onnx_light.onnx.helper as oh
import onnx_light.onnx.numpy_helper as onh
from onnx_light.tools import translate, translate_header

# Built-in operator schemas are registered so the rebuilt models validate.
defs.register_onnx_operator_set_schema()

Build the model#

A tiny graph Y = Add(Mul(X, W), B) with two initializers so the translation exercises nodes, inputs/outputs and initializers.

model = oh.make_model(
    oh.make_graph(
        [oh.make_node("Mul", ["X", "W"], ["XW"]), oh.make_node("Add", ["XW", "B"], ["Y"])],
        "linear",
        [oh.make_tensor_value_info("X", onnx.TensorProto.FLOAT, ["N", 3])],
        [oh.make_tensor_value_info("Y", onnx.TensorProto.FLOAT, ["N", 3])],
        [
            onh.from_array(np.array([1.0, 2.0, 3.0], dtype=np.float32), name="W"),
            onh.from_array(np.array([0.5, 0.5, 0.5], dtype=np.float32), name="B"),
        ],
    ),
    opset_imports=[oh.make_opsetid("", 18)],
    ir_version=8,
)

onnx-compact flavour#

translate_header("onnx-compact") returns the imports and translate(model, api="onnx-compact") the nested oh.make_model expression.

compact_code = translate_header("onnx-compact") + translate(model, api="onnx-compact")
print("=== onnx-compact ===")
print(compact_code)

=== onnx-compact ===
import numpy as np
import ml_dtypes
import onnx_light.onnx as onnx
import onnx_light.onnx.helper as oh
import onnx_light.onnx.numpy_helper as onh
model = oh.make_model(
    oh.make_graph(
        [
            oh.make_node('Mul', ['X', 'W'], ['XW']),
            oh.make_node('Add', ['XW', 'B'], ['Y']),
        ],
        'linear',
        [
            oh.make_tensor_value_info('X', onnx.TensorProto.FLOAT, ('N', 3)),
        ],
        [
            oh.make_tensor_value_info('Y', onnx.TensorProto.FLOAT, ('N', 3)),
        ],
        [
            onh.from_array(np.array([1.0, 2.0, 3.0], dtype=np.float32), name='W'),
            onh.from_array(np.array([0.5, 0.5, 0.5], dtype=np.float32), name='B'),
        ],
    ),
    opset_imports=[oh.make_opsetid('', 18)],
    ir_version=8,
)

builder flavour#

The builder flavour rebuilds the same model step by step with the GraphBuilder.

builder_code = translate_header("builder") + translate(model, api="builder")
print("\n=== builder ===")
print(builder_code)

=== builder ===
import numpy as np
import ml_dtypes
import onnx_light.onnx as onnx
import onnx_light.onnx.helper as oh
import onnx_light.onnx.numpy_helper as onh
from onnx_light.onnx_core.graph_builder import GraphBuilder
g = GraphBuilder('linear')
g.set_opset_version('', 18)
g.make_input(oh.make_tensor_value_info('X', onnx.TensorProto.FLOAT, ('N', 3)))
g.make_initializer(onh.from_array(np.array([1.0, 2.0, 3.0], dtype=np.float32), name='W'))
g.make_initializer(onh.from_array(np.array([0.5, 0.5, 0.5], dtype=np.float32), name='B'))
g.make_node('Mul', ['X', 'W'], outputs=['XW'])
g.make_node('Add', ['XW', 'B'], outputs=['Y'])
g.make_output(oh.make_tensor_value_info('Y', onnx.TensorProto.FLOAT, ('N', 3)))
model = g.to_onnx('model', ir_version=8)

Round-trip#

The generated code is plain Python: executing it rebuilds an equivalent model. Here we run the onnx-compact snippet and check that the rebuilt graph has the same nodes as the original.

namespace: dict = {}
exec(compact_code, namespace)  # noqa: S102
rebuilt = namespace["model"]

original_ops = [node.op_type for node in model.graph.node]
rebuilt_ops = [node.op_type for node in rebuilt.graph.node]
print("\n=== round-trip ===")
print("original ops:", original_ops)
print("rebuilt ops :", rebuilt_ops)
assert original_ops == rebuilt_ops

=== round-trip ===
original ops: ['Mul', 'Add']
rebuilt ops : ['Mul', 'Add']

Total running time of the script: (0 minutes 0.007 seconds)
